Tools Needed
Parts Needed
ASCEND Shower Door Manual Ver 1 022021 12
© 2021 DreamLine® All Rights Reserved
The Door Glass has a Top
and a Bottom. Look for a
sticker indicating the Top
of the glass.
!
Install the Glass Profile (#07) to the Pivots (#06) using the M6 x 16mm Screws (#09). Note the Glass Bracket
(#08) installs inside the top of the Glass Profile (#07). Be sure the holes in the Glass Profile face the inside of
the shower. Be sure all the screws are tight. Fig 5
NOTE
TIP
Be sure the holes in the
Glass Profiles (#07) face
the inside of the shower.
08
x1
09
x4
07
x1
2
Inside of
Shower
1
Fig 5
TOP
5
To Next Page
