Drufomat scan
34
6. Functional components
10
8
9
13
6
11
12
5
4
3
2
1
7
No. Description
1 scanner
2 display
3 keypad
4 heating element
5 handle heating
6 F insert
7 drawer for granules
8 push button
9 compressed air supply
10 handle plate reception
11 plate reception
12 exhaust valve
13 tension ring
33 mains supply/main breaker
