Table 57-1:
Models XTP 002 through 048 replacement parts
Item Description Part No.
1
Transformer, 120V, 24V SEC - QC 408965-101
Transformer, 208/240/480V, 24V SEC - QC 408965-102
Transformer, 277V, 24V SEC - QC 408982-101
Transformer, 600V, 24V SEC - QC 408986-101
Transformer, 230/400, 24V SEC - QC 408985-101
2 Contactor 407010-*
3 Plug, high water sensor 530010-105
4
Board, current sensing, 208/230/240/277 V
(Model XTP 002)
530013-001
Board, current sensing, 400/480 V 530013-002
Board, current sensing, 600 V 530013-003
Board, current sensing, 208/230/240/277/400 V 530013-004
5 Display board, Vapor-logic controller 408495-004
6 Main board, Vapor-logic controller 183504-004
7 Kit, electrode wiring (plugs/wires: 1 red, 1 black, 1 white) 194625-001
8* Kit, cylinder 194601-*
9 Strainer, cylinder 531006
10 Drain valve assembly (see parts in Figure 51-1) 194610-001
11
Fill valve assembly Models XTP 002 and 017 194623-001
Fill valve assembly Models XTP 025 through 096 194623-002
12 Kit, fi ll cup extension (see parts in Figure 11-1) 194605-101
13 Fuse 2A 600V ATM 406740-014
14 Switch interlock with override 530010-102
15
Fuse 40A 480V AG (XTP 042, 480 volt only) 406720-040
Fuse 50A 480V AG (XTP 048, 480 volt only) 406720-050
16 Switch auxiliary GE ECLA211S 407001-024
*
See cylinder Part No. on your XT Series humidifi er.
MAINTENANCE
Replacement parts
