5
Assembly Instructions Cont.
8. Release the spring loaded shaft on
the hi/low motor and insert the shaft
into the gear box on the footboard.
9. Make sure the slot on the spring
loaded shaft engages the roll pin on
the gear box.
10. Raise the Head Spring and Foot Spring to release tension between the springs and connect Head and
Foot spring fabric by squeezing together and attaching with spring links.
