3. UNPACKING THE MACHINE
3.1 Moving and handling the packed machine
The machine has been carefully wrapped with bubble plastic and cellophane plastic and tightened
to a wooden pallet, which is specially adapted for unpacking the machine more quickly.
You ll find the dimensions of the packed machine in picture 3-1:
Compacta 16 Compacta 24 Compacta 32
Width (mm/Inch) 720/28.35 850/33.5 850/33.5
Depth (mm/Inch) 705/27.75 1500/59.1 1500/59.1
Height (mm/Inch) 1370/53.93 1550/61 1550/61
Weight (kg) 330 370 380
picture 3-1
3.2 Unpacking
The following is the procedure for unpacking the Compacta:
a) Cut the plastic folio and bubble plastic.
b) Screw all four stabilisers clockwise until they reach the floor.
c) Screw them another 1 cm until the machine comes loose from the pallet.
d) Remove the pallet under the machine.
e) Screw the stabilisers anti-clockwise until the wheels touch the floor.
f) Place the machine in its final location.
g) Screw the stabilisers clockwise until the wheels come off the ground.
REMARKS
USE A RATCHET OR AN ELECTRIC DEVICE FOR THE
ABOVE WRITTEN PROCEDURE
