Compacta - User s Manual
Compacta User_en ed 1 Feb 05.doc
Page
15
of 34
The following is a description of the functions of each electronic board.
N°
Description
01
Driver for the stepping motor
02
Electronic board for powering the machine
03
Mother board with core module
04
Transformer for logic
05
Transformer for the stepping motors
06
Transformer for services
4-8
4.4.4
Elevator
On the Compacta dispenser two different types of elevator can be installed: manual or automatic
version.
Manual elevator
The Compacta is equipped with a manual shelf. Highering or lowering the shelf can be done
tearing the handle that you'll find on the bottomside of the shelf. After the shelf is positioned in
its position the handle is relieved and the shelf will be blocked in its position.
Automatic elevator
The elevator has a motor integrated which highers/lowers the cans until they are detected by the
photocell . Operating the elevator is very easy and effortless: just pushing the vertical arrows on
the display moves the elevator up and down.
The elevator stops automatically when the photocell detects a can.
4.5
Options
4.5.1
Printer
There is the possibility to connect a printer to the Prima software. Follow the instructions for
installation that comes with the printer and read the software manuals.
