Compacta - User s Manual
Compacta User_en ed 1 Feb 05.doc
Page
22
of 34
5.7
Setting the scale
The installed scale must have the following set up:
Bits per second
9600
Data bits
8
Parity
none
Stop bits
1
5.8
Filling the canisters
Before switching the dispenser on you have to verify that all the valves on the underside of the
canisters are open (see
5-7). They are open when they re vertically positioned.
WARNING
A VALVE THAT IS CLOSED CAN CAUSE A BLOW-UP OF THE TUBE WHEN
THE MACHINE IS IN RECIRCULATION OR IN DOSING. THE TAPS ARE
OPEN WHEN THEY ARE VERTICALLY POSITIONED (SEE PHOTO 5.10).
Do not clean the canisters and the pipelines as this operation has already been carried out in
Dromont.
5-7
Canister valves
