4.4.3 Electronic boards
The Compacta is equipped with three exchangeable electronic boards (see picture 4-6). Each of
which has their specific function declared in the accompanying table. The boards are accessible
by opening the backdoor. The boards can be taken out by unscrewing them from the metal plate.
Three transformers supply the necessary voltage to the electronic boards and machine ( picture
4-7 )
WARNING
O N L Y Q U A L I F I E D T E C N I C I A N S M A Y W O R K O N
T H E E L E C T R O N I C S / E L E C T R I C S .
WARNING
P L E A S E M A K E S U R E Y O U T A K E T H E R I G H T
S A F E T Y M E A S U R E M E N T S B E F O R E W O R K I N G
O N / I N S I D E T H E M A C H I N E .
P L E A S E T A K E N O T I C E O F T H E S A F E T Y
S T I C K E R S O N T H E B A C K O F T H E M A C H I N E .
picture 4-6 Electronic boards picture 4-7 Transformers
