Compacta - User s Manual
Compacta User_en ed 1 Feb 05.doc
Page
24
of 34
After carrying out the before mentioned operations you are finally ready to work with the
machine.
As you can see on the display you have 2 vertical arrow, two horizontal arrows and 3 buttons named:
- ENTER
- MENU
- RESET
Pressing the MENU button you move into the functions described in the following table
Pressing < > button you move in the submenu.
Pressing ENTER button you confirm the selected function
Pressing RESET you exit to the MENU
PUSH
FUNCTION
CHOOSE BY PRESSING
EXPLANATION
2xMENU
M2> MIX
ENTER = ACTIVATE
Start recirculation cycle (see chapter 5.9.2 )
3xMENU
M3> PURGE
ENTER = ACTIVATE
Start purge cycle (cleaning nozzles) (see chapter
5.9.1)
4xMENU
M4> MANUAL
DISP
(only for internal
canisters)
VERTICAL ARROWS =
INCREASE/DECREASE THE
VALUE
HORIZONTAL ARROW = SHIFT
THE CURSOR
CODE = #01 = 0000,0 1/96
#01
= canister number. When there is no
colorant or k1 or k2 or S.G. are missed,
?01
will
appear on the display)
0000,0
= quantity in disp. Unit
1/96
= disp. Unit set in D_SET
5xMENU
M5> LANGUAGE
HORIZONTAL ARROWS
Choose between English and Italian
5-9
