Location
Signal level
Function
Note
Block
Num
M3
1
0:10V
0:10 V input
Analog input 0:10V to
future expansion
Not isolated, not buffered , load 20 Kohm
2
0 V
0:10 V reference
3
4:20mA
4:20 mA input
Analog input 4:20mA to
future expansion
Not isolated, not buffered, load 220R
4
0 V
4:20 mA reference
5
4:20mA
4:20 mA input
Analog input 4:20mA to
future expansion
Not isolated, not buffered, load 100R
6
0 V
4:20 mA reference
Location
Signal level
Function
Note
Block
Num
M4
1
C
SPST, 3 A 250Vac
resistive load
Command "Alarm" on
Vip5 Pro panel
2
NC
3
NO
4
C
SPST, 3 A 250Vac
resistive load
Command cleaning
nozzles
5
NO
6
C
SPST, 3 A 250Vac
resistive load
Load command
7
NO
8
C
SPST, 3 A 250Vac
resistive load
Low alarm level
9
NC
10
NO
11
C
SPST, 3 A 250Vac
resistive load
General alarm
12
NC
13
NO
14
C
SPST, 3 A 250Vac
resistive load
Main pump control
15
NO
16
C
SPST, 3 A 250Vac
resistive load
Main pump control
17
NC
18
NO
Location
Signal level
Function
Note
Block
Num
M5
1
V inv
SPST-NO
30 A 250Vac, 20 A 28Vdc
Inverter command line 1
Direct load
2
NO
Dial, contact NO
3
V inv
Direct load
Power inverter line
Bring the voltage at these terminals for the
type of inverter used
4
C
line of contact C
5
V inv
SPST-NO
30 A 250Vac, 20 A 28Vdc
Inverter command line 2
Direct load
6
NO
Dial, contact NO
Location
Signal level
Function
Note
Block
Num
M6
1
Vint +
Positive power
Power on board 1639186
2
Vint -
Negative power
3
24V
Pump control
4
0 V
Location
Signal level
Function
Note
Block
Num
M7
1
24 Vdc
Positive power
Power Inverter Line
For 24Vdc inverter
2
0 Vdc
Negative power
