INSTALLATION MANUAL
Preface
DRU, a manufacturer of gas-fi red heating appliances,
develops and produces products that comply with the
highest quality, performance and safety requirements.
This guarantees that the user will be able to enjoy using his
product for many years to come.
This appliance has a CE marking, which means that it
complies with the essential requirements of the European
gas appliance directive.
Two manuals are supplied with the appliance: the installa-
tion manual and the user manual. These have been included
in one booklet.
In addition, the booklet “fi tting into a conventional class 1
chimney” has been added for Great-Britain.
As an installer, you must be competent in the fi eld of
atmospheric gas-fi red heating.
The installation manual will give you the information you
need to install the appliance in such a way that it will
operate properly and safely.
This manual discusses the installation of the appliance and
the regulations that apply to the installation. In addition, you
will fi nd technical data for the appliance and information on
maintenance, any malfunctions that might occur and their
possible causes.
The fi gures are included at the back of this booklet
(Appendix 3).
Please carefully read and use this installation manual.
The following symbols are used in the manual to indicate
important information:
• Work to be performed.
! Tip Suggestions and recommendations.
! Caution You will need these instructions to prevent
problems that might occur during installa-
tion and/or use.
You need these instructions to prevent fi re,
personal injury or other serious damages.
After delivery you should give this booklet containing
the manuals to the user.
1. Introduction
The Global 40 CF is an open-fl ued atmospheric gas-
fi red heating appliance. An open-fl ued appliance draws its
combustion air from the living area. The living area must
be ventilated suffi ciently, in order to provide the appliance
with combustion air. To guarantee a safe operation of the
appliance, an oxypilot safety is installed. If the supply of air
is insuffi cient, the oxypilot will interfere and switch off the
appliance.
Global 40 CF is suitable for construction in a newly instal-
led chimney breast. Construction in a mantelpiece/fi replace
connected to an existing chimney (class 1 chimney) is only
allowed in Great Britain.
This manual describes the construction of the appliance in
a chimney breast.
The separate English description for connection to an exis-
ting chimney is only intended for Great Britain.
The appliance must be fi tted tightly using a plaster strip
(frameless) or provided with a front. These parts are not
provided with the appliance as standard, but are available
upon request. The installation instructions are provided
with the part concerned.
In order to reach a proper heat discharge, the chimney
breast must be ventilated. DRU is able to supply various
ventilation elements.
The appliances are supplied with a wireless remote control
that works on batteries.
2. CE declaration
We hereby declare that the design and construction of
DRU’s atmospheric gas-fi red heating appliance comply with
the essential requirements of the Gas Appliance Directive.
Product: atmospheric gas-fi red heating appliance
Type: Global 40 CF
Applicable EEC directives:
2009/142/EC
Applied harmonized standards:
NEN-EN-613
NEN-EN-613/A1
Internal measures by the company guarantee that applian-
ces produced in series comply with the essential require-
ments of the prevailing EEC directives and the standards
derived from them.
This declaration will lose its validity if adjustments are made
to the appliance, without prior written permission by DRU.
M.J.M. Gelten
General manager
DRU verwarming B.V.
Postbus 1021, 6920 BA Duiven
Ratio 8, 6921 RW Duiven
www.dru.nl
3. Safety
3.1 General
- Carefully read this chapter on safety,
before you start performing instal-
lation or maintenance work;
- Please observe the general regu-
lations and the precautions/safety
instructions in this manual.
3.2 Regulations
Please install the appliance in accordance with the
applicable national, local and constructional (installation)
regulations.
Caution
Caution
