INSTALLATION MANUAL
Appendix 1 Parts included with the delivery
In the following table you can fi nd the parts that are supplied with the appliance.
Table 2: Parts included with the delivery
Part Quantity
Wood set 1x
Plaster strip/Front (Sigma)* 1x
Booklet containing the manuals 1x
Installation instructions for fi tting into a conventional class 1 chimney** 1x
Foam seal**
Insulation tape self-adhesive***
Debris shield** 1x
Key bolts M6 3x
Hexagonal nut M6 3x
Washer 3x
Allen key 5 mm 1x
Remote control 1x
9V block battery 1x
Penlite battery (AA type) 4x
* upon request, the plaster strip, decorative strip or front will be included in the delivery
** only intended for the UK
*** intended for plaster strip
Appendix 2 Technical data
In the following tables you will fi nd the technical data for the Global 40 CF.
Table 3: Technical data
Type B
11AS
Type of gas G20 G25 G31
Burner pressure mbar 15,4 19 26
Nominal heat input (Hs) kW 4,8 4,4 4,9
Nominal heat input (Hi) kW 4,3 4 4,4
Nominal output kW 3,3 3 3,1
Consumption L/h 457 480 178
Burner injector mm Ø 1,65 Ø 1,65 Ø 1,15
Consumption on low output L/h 219 228 80
Low setting injector mm Ø 1,4 Ø 1,4 Ø 0,9
Effi ciency class 2 2 2
Table 4: Line-pressure when using G31
Country mbar
NL / DK / FI / NO / SE / HU / BA / GR 30
FR / BE / IT / PT / ES / GB / IE 37
DE 50
