INSTALLATION MANUAL
Preface
DRU, a manufacturer of gas- red heating appliances,
develops and produces products that comply with the
highest quality, performance and safety requirements.
This guarantees that the user will be able to enjoy using his
product for many years to come.
This appliance has a CE marking, which means that it
complies with the essential requirements of the European
gas appliance directive.
Two manuals are supplied with the appliance: the installa-
tion manual and the user manual. These have been included
in one booklet.
In addition, 2 bookslets are included which are intended for
the United Kingdom, the ‘Concise installation guide’ and
‘Fitting into a conventional class 1 chimney’.
As an installer, you must be competent in the  eld of
atmospheric gas- red heating.
The installation manual will give you the information you
need to install the appliance in such a way that it will
operate properly and safely.
This manual discusses the installation of the appliance and
the regulations that apply to the installation. In addition, you
will  nd technical data for the appliance and information on
maintenance, any malfunctions that might occur and their
possible causes.
The  gures are included at the back of this booklet
(Appendix 3).
Please carefully read and use this installation manual.
The following symbols are used in the manual to indicate
important information:
• Work to be performed.
! Tip Suggestions and recommendations.
! Caution You will need these instructions to prevent
problems that might occur during installa-
tion and/or use.
You need these instructions to prevent  re,
personal injury or other serious damages.
After delivery you should give this booklet containing
the manuals to the user.
1. Introduction
The Global 70XT CF is an open- ued atmospheric gas-
 red heating appliance. An open- ued appliance draws its
combustion air from the living area. The living area must
be ventilated suf ciently, in order to provide the appliance
with combustion air. To guarantee a safe operation of the
appliance, an oxypilot safety is installed. If the supply of air
is insuf cient, the oxypilot will interfere and switch off the
appliance.
Global 70XT CF is suitable for construction in a newly
installed chimney breast or existing mantelpiece/ replace.
In an existing chimney (other than the class 1 chimney in
the UK), a  exible SS pipe is recommended for discharging
the  ue gases. This manual describes the construction of
the appliance in a chimney breast. When constructed in a
mantelpiece/ replace connected to an existing chimny in
the United Kingdom (class 1 chimney), the separately sup-
plied English description ‘Fitting into a conventional class 1
chimney’ also applies.
The appliance must be  tted tightly using a plaster strip
(frameless) or provided with a surrounding decorative strip
or front. These parts are not provided with the appliance
as standard, but are available upon request. The installation
instructions are provided with the part concerned.
In most cases, the chimney breast must be ventilated in
order to achieve a good heat discharge (see chapter 6.6).
DRU is able to supply various ventilation elements.
The appliances are supplied with a wireless remote control
that works on batteries.
2. CE declaration
We hereby declare that the design and construction of
DRU’s atmospheric gas- red heating appliance comply with
the essential requirements of the Gas Appliance Directive.
Product: atmospheric gas- red heating appliance
Type: Global 70XT CF
Applicable EEC directives:
2009/142/EC
Applied harmonized standards:
NEN-EN-613
NEN-EN-613/A1
Internal measures by the company guarantee that applian-
ces produced in series comply with the essential require-
ments of the prevailing EEC directives and the standards
derived from them.
This declaration will lose its validity if adjustments are made
to the appliance, without prior written permission by DRU.
M.J.M. Gelten
General manager
DRU verwarming B.V.
Postbus 1021, 6920 BA Duiven
Ratio 8, 6921 RW Duiven
www.dru.nl
3. Safety
3.1 General
- Carefully read this chapter on safety,
before you start performing instal-
lation or maintenance work;
- Please observe the general regu-
lations and the precautions/safety
instructions in this manual.
3.2 Regulations
Please install the appliance in accordance with the
applicable national, local and constructional (installation)
regulations.
Caution
Caution
