English
29
INSTALLATION MANUAL
Global 70XT CF
Do not ignite the appliance until it is fully
installed.
7.1 Connecting the receiver
The receiver should be connected to the appliance, before the
batteries are installed.
The receiver will be placed in the tray below the burner.
Follow the procedure below (see g. 11a):
• Fit the connection cable’s brown plug to the receiver (see
g. 11a, arrow F).
• Connect the white plug to the gas control.
!Tip The plugs have different sizes that cor-
respond with the connectors.
• Connect the cables of the thermocouple to the receiver;
(see g. 11a, arrows B).
!Tip - The size of the eye corresponds with the
size of the screw;
- The colours of eye and screw also cor-
respond.
• Connect the black wire with the white plug of
thermocouple 2 to the receiver (see g. 11a, arrow E).
!Caution - Make sure that the wires of
thermocouple 2 cannot come into con-
tact with hot parts;
- Make sure the ignition cable cannot come
into contact with other wires.
• Connect the ignition cable to the receiver;
(see g. 11a, arrow A).
!Caution The battery holder is lying in a small tray at
the bottom of the slot between the com-
bustion chamber and the convection box.
• Connect the cable of the battery holder to the receiver
(see g.11a, Arrow C and g. 11b).
• Place the receiver in the tray below the burner and bend
the clip (see g. 11b, Arrow).
!Caution First read section 7.1.1 and 7.2 before
bending the clip.
• Bend the antenna out of the clips; see g. 11a, arrow D.
• Set the antenna straight.
!Caution - Do not place the antenna too close to
the ignition cable and/or metal parts;
- Do not place the ignition cable over and/
or along metal parts: this will weaken the
spark;
- Do not lay the ignition cable over the
receiver: this could damage the receiver;
- Avoid dust on or in the receiver: cover it
when performing work.
7.1.1 Placing/replacing receiver’s batteries
The batteries should be placed in the special battery holder
and not in the receiver.
Strictly observe this, to avoid damages to
the receiver.
The battery holder is lying in a small tray at the bottom of
the slot between the combustion chamber and the con-
vection box. By pulling the (guide) ribbon towards you, the
battery holder will appear. (see User Manual, g. 1 and g.
2a up to 2d).
To place/replace the batteries, proceed as follows:
• Pull the (guide) ribbon towards you.
• Grab the battery holder.
• Loosen the screw.
• Slide the cover off.
• Remove and place the 4 penlite (AA type) batteries.
!Caution - Avoid a short circuit between the bat-
teries and metal objects/parts;
- Observe the “+” and “-” poles of the bat-
teries and the holder;
- Use alkaline batteries;
- Batteries are regarded as “small chemical
waste” and may therefore not be dis-
posed with the household rubbish.
• Slide back the cover.
• Tighten the cover.
• Place back the holder.
!Caution Make sure the guide ribbon is under the
holder.
7.2. Setting the communication code
Prior to putting the appliance into operation, a communica-
tion code must be set between the remote control and the
receiver.
When installing a new receiver or remote control, you must
set a new communication code.
The code is chosen randomly from the 65000 available codes.
As a result, the chance that other remote controls near you
are using the same code and affect the operation of your
appliance is very small.
Follow the procedure described below:
• If necessary, place the receiver’s batteries in the battery
holder; see section 7.1.1.
• If necessary, place the remote control’s 9V block battery; see
User Manual , section 4.2.6
• Remove the receiver from the tray below the burner; if
necessary see section 7.3.
• Hold down the reset button on the receiver, until you hear
two consecutive sound signals (see g. 12).
• After the second, longer signal, let go of the reset button.
•Press the 'small ame' button on the remote control for 20
seconds, until you hear two short sound signals: this is the
con rmation of a good communication.
