INSTALLATION MANUAL
Global 70XT CF
• If necessary, correct the above mentioned faults.
• Test the main burner 5x for a good operation.
2) If the main burner ignites, but goes out again after
approx. 22 seconds, please:
• Check the wiring of thermocouple 2 for:
- Loose wiring;
- Wrongly connected wiring;
- Short-circuit;
- Broken wire.
• Check if thermocouple 2 is dirty.
• Check if thermocouple 2 is positioned correctly in the
 ame; see  g. 5b.
• Check if thermocouple 2 is defective; see chapter 11,
table 4 under J7.
• Check if the receiver is defective; see chapter 11, table 4
under J8.
• If necessary, correct the above mentioned faults.
• Test the main burner 5x for a good operation.
8.4 Flame image
The  ame image can only really be assessed when the
appliance has been burning for several hours. Volatile
components from paint, materials, etc., which evaporate in
the  rst hours, will affect the  ame image.
!Caution If the chimney breast is made of stone-
like materials or has a plaster  nish, this
may only take place 6 weeks after placing
the chimney breast, in order to prevent
shrinkage cracks.
• Check whether the  ame image is acceptable.
If the  ame image is not acceptable, this can be due to:
- the evaporation of volatile substances;
- incorrect placement of the wood set.
• If necessary, improve the placement of the wood set.
9. Maintenance
Once a year the appliance should be checked, cleaned and,
if necessary, repaired by a competent installer in the  eld of
atmospheric gas- red heating.
Check at least whether the appliance is working properly
and safely.
- Close the gas tap when performing
maintenance work;
- Check the gastightness after repair;
- After replacing the thermocouple you
should  rst tighten the swivel by hand and
then give it another quarter turn with a
suitable spanner;
- Do not turn the pilot burner lower by
using the settings on the gas control.
• If required, clean the following components:
- the pilot burner;
- the space surrounding the pilot burner;
- thermocouple 2
- the glass pane.
!Caution - Remove/place the glass pane as described
in section 6.8;
- Remove the deposit on the inside of the
glass pane with a damp cloth or a non-
abrasive detergent such as copper polish;
- Avoid/remove  ngerprints on the glass
pane, since otherwise they will burn into
the surface;
- Replace a broken and/or cracked glass
pane, as described in section 6.8.
If necessary, place back the wood set
correctly; for this, see section 6.7.
• Inspect the  ue gas discharge system.
You must always perform a  nal check.
• Perform a check as described in chapter 8.
9.1 Parts
Parts that must be replaced, can be obtained from your
supplier.
10. Delivery
You must explain to the user how he should operate the
appliance. You should instruct her/him for instance on using
the appliance for the  rst time, the operation of the remote
control, annual maintenance.
- Tell the user to close the gas tap immedi-
ately in case of malfunctions/bad perfor-
mance and contact the installer in order
to prevent dangerous situations;
- Indicate the location of the gas tap;
- Point out the precautions in the user
manual concerning unintended ignition by
other remote controls such as car keys
and garage door openers.
• Instruct the user about the appliance and the remote
control.
• When the appliance is started for the  rst time, point out
that
- in order to avoid cracks in a chimney breast made of
stone-like materials or  nished with plaster, it should dry
for at least 6 weeks prior to putting the appliance into
operation
- when the appliance is stoked up for the  rst time, volatile
components evaporate from paint, materials, etc.;
- when evaporating, the appliance should preferably be set
at the highest level;
- the room should be well ventilated.
• Give this booklet containing the manuals to the user
(the booklet should be kept near the appliance).
