Global 70XT CF
English
35
INSTALLATION MANUAL
Appendix 1 Parts included with the delivery
In the following table you can nd the parts that are supplied with the appliance.
Table 2: Parts included with the delivery
Part Quantity
Wood set 1x
Plaster strip/decorative strip (Frame Alpha)/front (Frame Bèta)* 1x
Booklet containing the manuals 1x
Concise installation guide** 1x
Installation instructions for tting into a conventional class 1 chimney** 1x
Foam seal**
Debris shield** 1x
Key bolts M6 4x
Hexagonal nut M6 4x
Washer 4x
Spare Allen screws for mounting the glass pane 3x
Allen key 5 mm 1x
Remote control 1x
9V block battery 1x
Penlite battery (AA type) 4x
* upon request, the plaster strip, decorative strip or front will be included in the delivery
** only intended for the United Kingdom
Appendix 2 Technical data
In the following tables you will nd the technical data for the Global 70XT CF.
Table 3: Technical data
Type B
11AS
Type of gas G20 G25,3 (G25) G31
Burner pressure mbar 14,5 18,2 27
Nominal heat input (Hs) kW 6,9 6,7 6,9
Nominal heat input (Hi) kW 6,2 6,0 6,2
Nominal output kW 4,7 4,6 4,8
Consumption L/h 657 712 252
Burner injector mm 7x Ø 0,81 7x Ø 0,81 7x Ø 0,55
Consumption on low output L/h 297 317 147
Low setting injector mm Ø 1,45 Ø 1,45 Ø 1,10
Ef ciency class 2 2 2
Country mbar
NL / DK / FI / NO / SE / HU / BA / GR 30
FR / BE / IT / PT / ES / GB / IE 37
DE 50
Table 4: Line-pressure when using G31
