DSC Classic PC1565 - Table of Contents

Table of Contents
Features .................................................1
Installation .............................................2
Installing the Classic PC1565
Control Panel ...............................2
Wiring ....................................................4
Wiring Keybus..............................4
Wiring 24-hr Devices....................5
Wiring PIRs ..................................6
Wiring Fire Detectors ...................7
Wiring SAB ..................................8
Telephones...........................................10
Telephone Connections..............10
Power Up..............................................11
Initial Start Up............................11
Common Start-Up Problems......17
Default Settings....................................15
Classic PC1565 Expansion Flowchart...16
[*] Commands .....................................18
Clearing Troubles .................................21
Basic Programming .............................24
Programming Using
an LED Keypad..........................27
Programming Using
an LCD Keypad..........................28
Translation ...........................................29
The Language Barrier ................29
Using the Big Books.............................30
Using the Big Books
The summary of programme options
is also a good troubleshooting tool.
For example, if you are having diffi-
culty getting the panel to send a test
transmission, look this feature up in
the Installation Manual. Refer to the
summary and make sure you have
programmed all the required informa-
tion. If you think you missed an item,
the summary will tell you exactly what
programming section you need to
look at to check the item.
The other book named Instruction
Manual should be given to the client
or on-site manager.
For more detailed information, please
refer to the Installation Manual.
