DSC MAXSYS PC4020 System Manual

9
PC4400 Serial Interface Module
• True RS-232 technology
• Handshake software switches
• Protocol XON/XOFF or DTR
• 5 possible baud rates 300, 600, 1200, 2400 and 4800
• DVAC communications†
• Four wire (QUAD) hook-up to Combus
• Nominal current draw of 35 mA
• Provides Tamper Reporting Codes
• Low Combus supervision to PC4020 Main Board
Note: 4800 Baud is only available on PC4400 software
version 2.00 and above.
LCD4500 Remote Keypad
• Up to 16 keypads on system
• Alphanumeric liquid crystal display
• Built-in piezoelectric buzzer
• Full annunciation of zones and system status
• Four wire (QUAD) hook-up to Combus
• Nominal current draw of 55 mA
• Provides Tamper Reporting Codes
• Low Combus supervision to PC4020 Main Board
• Dimensions 5.75" x 4.5" x 1" deep (144 x 114 x 25 mm)
Escort4580 (Voice Prompting Module)*
• One module per system
• Full voice prompts for all major user accessible
sections
• Four wire quad connection to Combus
• Nominal current draw of 70 mA - 140 mA
• Automation Control capabilities - up to 32 Automation
Module per system
• Low Combus supervision to the main board
* These devices are not UL listed.
† These features have not been investigated by UL.
PC4108 Expansion Module
• Up to 128 zones total on system
• 8 zone expansion module
• Normally closed loops, EOL resistor, Double EOL
resistor support
• Four wire (QUAD) hook-up to Combus
• Nominal current draw of 25 mA
• Provides Tamper Reporting Codes
• Low Combus supervision to PC4020 Main Board
PC4116 Expansion Module
• Up to 128 zones in total on system
• Normally closed loops, EOL resistor, Double EOL
resistor support
• 16 zone expansion module
• Four wire (QUAD) hook-up to Combus
• Nominal current draw of 30 mA
• Provides Tamper Reporting Codes
• Low Combus supervision to PC4020 Main Board
PC4164 Expansion Module*
• Up to 64 zones in total on the system
• One module per system
• 64 zone wireless expansion module
• Support for Universal transmitters and PIRs
• Normally closed and zone module tamper support
• 4 wire quad hookup to the PC4164
• Nominal current draw of 110 mA
• Provides zone alarm/zone low battery/zone tamper
reporting codes
• Low Combus supervision to the PC4020
PC4204 High Current Output Module
• 4 output high current module
• Up to 16 modules on system
• Minimum 40 VA 16-18 volt transformer required
• Minimum 4 Amp-Hour, 12 volt battery required
• Each output programmable for 1 of 35 options
• Four wire (QUAD) hook-up to Combus
• Nominal current draw of 25 mA
• Provides Tamper and Trouble Reporting Codes
• Low Combus supervision to PC4020 Main Board
• 1.5 Amp output
PC4216 Low Current Output Module
• 16 output low current module
• Up to 9 modules on system
• All module programmable for all 16 outputs, 1 of 35
options for each
• Programmable as alarm annunciators or zone followers
• Four wire (QUAD) hook-up to Combus
• Nominal current draw of 15 mA
• Provides Tamper Reporting Codes
• Low Combus supervision to PC4020 Main Board
MODULE
SPECIFICATIONS

DSC MAXSYS PC4020 Specifications

General

Partitions	8
Event Buffer	1000 events
Keypads	16
Power Supply	16.5V, 40VA transformer
Battery Backup	12V 7Ah (typical)
