Maximum System Capabilities
• Control Units - 1 PC4020 Main Board
• 128 Zones
PC4020 Main Board: 16 zones
PC4108 Expansion Module: 8 zones
PC4116 Expansion Module: 16 zones
PC4164 Expansion Module: 64 wireless zones
• 64 High Current Outputs - Up to 16 PC4204 Modules
• 144 Low Current Outputs
- 9 PC4216 16 Output Modules
• PC4400 Serial Interface module : Serial Printer / or
DVACS
• PC4700 Fire Module Support
• 16 Remote LCD Keypads - LCD4500
• Escort4580 Voice Prompting Module
• 1 Main Board Fully Programmable Output
• 1 12 V
DC Switched Fully Programmable Auxiliary Power
Supply (Main Board)
• Positive Temperature Coefficient (PTC) components
replace fuses
• 1 Supervised Fully Programmable Bell/Siren Output
(Main Board)
• 1 Telephone Interface (Main Board)
• 2 Telephone Interface (PC4700)
128 Programmable Zones
• 16 zones on main board expandable by using 8 and 16
zone modules
• 22 zone types including: instant, 2 types of interior, 3
delay, 4 fire, 7-24 hour, forced answer, momentary,
maintained arming, Links supervisory and Links answer.
• Zone expansion is done by enrolling a zone expansion
module
• Zones can be assigned independently to any
partition(s)
• Programmable for NC loops, EOL resistor or Double EOL
resistors
Escort4580 (VPM)
• All main user function accessible through the VPM
• Local and remote access abilities
• 241 word library for zone, access code and partition labelling
LCD Keypads (LCD4500)
• Total of 16 on the system
• Can be assigned to any partition
• Single keypad system control
209 Outputs
• 1 main board transistor switch to ground with 3A
capabilities (programmable for 1 of 28 options)
• 64 relay outputs programmable for 1 of 28 options each
(16-4204 modules with 4 outputs each)
• 144 switched transistor outputs programmable for 1 of
28 options each (9-4216 modules with 16 outputs)
Switched Auxiliary Output
• Programmable for 1 of 35 options
4 Enclosures
• PC4001C - PC4020 plus 2 modules
• PC4002C - 3 modules
• PC4003C - 1 module
• PC4004C - Attack resistant for PC4020 plus 2 modules
Supervised Alarm Output
• Bell Output, 700 mA, PTC 2.5 Amps,
12 V
DC - commercial and 11.6 - 12.6 VDC - residential
• Steady or Pulsed Output
• Programmable for 1 of 35 options
Event Buffer
• 600 events
• Date and time stamp
• Event Buffer Viewing - any System Master is able to
view 512 events through the keypad including date and
time stamp
• Event Buffer Printing - the entire event buffer (600 events)
can be printed at once through the Installer’s mode
8 True Partitions
• Separate or shared zones from other partitions
• Individual keypads per partition
• Individual access codes for each partition
• Individual keypad zones (Fire, Auxiliary, Panic)
• Individual outputs programmable per partition
Serial Interface Module (PC4400)
• Used to output data to a local printer
• Used to communicate to a DVAC network
Internal Memory
• Retains programmed data even when both AC and
Battery have been removed.
• The clock will have to be reset after a power down
condition which will be indicated by an audible trouble
beep and the keypad trouble LED is on.
Keypad User Options
They are all menu driven, including:
• Programming of several types of 4 or 6 digit access
codes, 128 in total
• Bypassing from the keypad by authorized personnel
• Utility functions such as remote control of lights, door
strikes, etc.
Communicator
• Communicates in all 10 and 20 BPS single line and
extended formats
• Radionics Rounds and Radionics Parity
• Sescoa Superfast format
• Ademco Contact ID format
• SIA 1986 format
• Sur-gard 4/3 DTMF format
• 3/1 and 4/2 formats
• Hexadecimal numbers
• DTMF and Pulse dialing
• DPDT line seizure
• True dial tone detect
• Anti-jam feature
• Three telephone numbers and nine account codes
LINKS Support (Not investigated by UL)
• 3 telephone numbers for LINKS
• Auto programming for LINKS zones
SYSTEM OVERVIEW
