If the zone is disarmed and the tamper (open) or fault
(short) condition is tripped a buzzer will sound from all
partition keypads for the length of Bell Time Out or until an
access code is entered. A zone tamper will be sent to the
monitoring station if programmed. See Reporting Codes
for details.
If the zone is armed and the tamper is activated, it will
transmit and log both the tamper alarm and the zone
alarm. There will be no buzzer sounded if the zone is
armed (unless the zone is programmed as a 24 hour
buzzer zone). See the “Control Panel Wiring Diagram” for
detail on the hookup procedure.
The type of circuit or zone definition (delay, instant, 24
hour, silent, audible, etc.) is programmed from the keypad
using the installers programming commands.
Telephone Terminals
“TIP”, “RNG ”, “T-1” and “R-1”
The wires from the RJ31-X telephone jack are connected
to these terminals in the following way.
Note: For proper operation, there must be no other
telephone equipment connected between the
control panel and the telephone company’s
facilities.
Ensure that plugs and jacks meet the dimension,
tolerance and metallic plating requirements of 47
C.F.R. Part 68 Subpart F.
TIP Green wire
Incoming line from
RNG Red wire
telephone company
T-1 Brown wire
Outgoing line to
R-1 Grey wire
house telephone(s)
Battery Connections
Do not connect the battery or the transformer until the
wiring is complete. Connect the red battery lead to the
positive battery terminal and the black lead to the
negative battery terminal. If the connection is reversed the
battery PTC will blow.
