DSC Neo Power HS2016 User Manual

Chapter 8
Trouble
Condition
Trouble
#
Level 1
Description
Trouble
Types
Trouble
#
Level 2
Trouble
Notification
Level 3
Module Super-
vision
09 The system has detected a supervisory trouble condition
with one or more modules on the system. Call for service.
HSM2HOST 01 n/a
Keypad 02 Keypad 1-16
Zone
Expander
04 Zone
Expander 1-
15
Power Supply 05 Power supply
1-4
High Current
Output
06 Output ter-
minal 1-4
Output
Expander
08 Output mod-
ule 1-16
Audio
Expander
09 n/a
Module
Tampers
10 The system has detected a tamper condition with one or
more modules on the system. Call for service.
HSM2HOST 01 n/a
Keypad 02 Keypad 1-16
Zone
Expander
04 Zone
Expander 1-
15
Power Supply 05 Power supply
1-4
High Current
Output
06 Output ter-
minal 1-4
Output
Expander
08 Output mod-
ule 1-16
Audio
Expander
09 n/a
Alt. Comm 10 n/a
Communications 11 The system has detected a communication trouble. Call for
service.
TLM Trouble 01 n/a
FTC Trouble 02 Receiver 1-4
SIM Lock 03 n/a
Cellular 04 n/a
Ethernet 05 n/a
Receiver 06 Receiver 1-4
Supervision
Receiver
07 Receiver 1-4
Alt Comm
Fault
09 n/a
Alt Comm
FTC
10 Receiver 1-4
Not Networked 12 The system has detected a network trouble condition with
one or more modules on the system. If the trouble does not
restore within 20 minutes, call for service.
Zone 01 Zone label
001-128
Keypad 02 Keypad 1-16
Siren 03 Siren 1-16
Repeater 04 Repeater 1-8
User 05 Users 01-
1000
- 32 -

DSC Neo Power HS2016 Specifications

General

Power Supply	16.5 VAC, 40 VA
Operating Temperature	0°C to 49°C (32°F to 120°F)
Event Buffer	500 events
PGM Outputs	2
Communications	PSTN
Humidity	Up to 85% non-condensing
Keypads	Up to 8
