DSC PC3OOO - Programming Work Sheets

Note: In sections [01] through [15], do not enter any data in sections that are not used.
[01] 1st Phone Number Page 14
• Be sure to enter [#] to end number
• Enter [0] for digit “0” in phone number
[02] 1st Account Code Page 15
• For 3 digit code enter [0] for last digit
• Enter [
Q1Q] (HEX A) for digit “0” in account code
i.e. Account code 103 would be [1]+[
Q1Q]+[3]+[0].
[03] 2nd Phone Number Page 15
[04] 2nd Account Code Page 15
[05] Alarm Reporting Codes Zones 1 to 8 Page 15
Zone 1 Alarm Zone 5 Alarm • For single digit reporting codes, enter [0] as 2nd digit
Zone 2 Alarm Zone 6 Alarm • Enter [Q1Q] (HEX A) to transmit a “0”.
Zone 3 Alarm Zone 7 Alarm (A “0” digit is 10 pulses.)
Zone 4 Alarm Zone 8 Alarm
[06] Alarm Reporting Codes Zones 9 to 16 Page 15
Zone 9 Alarm Zone 13 Alarm
Zone 10 Alarm Zone 14 Alarm
Zone 11 Alarm Zone 15 Alarm
Zone 12 Alarm Zone 16 Alarm
[07] Restoral Reporting Codes Zones 1 to 8 Page 15
Zone 1 Restoral Zone 5 Restoral
Zone 2 Restoral Zone 6 Restoral
Zone 3 Restoral Zone 7 Restoral
Zone 4 Restoral Zone 8 Restoral
[08] Restoral Reporting Codes Zones 9 to 16 Page 16
Zone 9 Restoral Zone 13 Restoral
Zone 10 Restoral Zone 14 Restoral
Zone 11 Restoral Zone 15 Restoral
Zone 12 Restoral Zone 16 Restoral
PROGRAMMING
WORK SHEETS
PC3000 Version 7.51
