DSC PowerSeries PC1832

PowerSeries - PC1616/PC1832/PC1864
12
Section [012] Keypad Lockout
The system can be programmed to ‘lockout’ keypads if a series of incorrect user or installer codes are entered. When lockout is active, all
keypads emit a steady 2-second error tone when a key is pressed. Program the Number of Invalid Codes Before Lockout with the desired
number. Valid entries are from [000] to [255]. Program data [000] to disable the feature. Keypads will remain locked out for the number of
minutes programmed for the Lockout Duration. Valid entries are from [000] to [255].
Section [013] First System Option Code
[18] Stay Armed Status: Activates when all of the selected partitions are armed in Stay mode
[19] Command Output 1:Activates when a [][7][1] command is entered on the selected partition – Command can be programmed to require a
valid access code and output can be programmed to activate for the time programmed in Section [170] or programmed to latch.
[20] Command Output 2: Activates when a [][7][2] command is entered on the selected partition – Command can be programmed to require
a valid access code and output can be programmed to activate for the time programmed in Section [170] or programmed to latch.
[21] Command Output 3: Activates when a [][7][3] command is entered on the selected partition – Command can be programmed to require
a valid access code and output can be programmed to activate for the time programmed in Section [170] or programmed to latch.
[22] Command Output 4: Activates when a [][7][4] command is entered on the selected partition – Command can be programmed to require
a valid access code and output can be programmed to activate for the time programmed in Section [170] or programmed to latch.
[23] Silent 24-Hour Input: Changes PGM to a 24-Hour Silent zone (PGM2 only)
[24] Audible 24-Hour Input: Changes PGM to a 24-Hour Audible zone (PGM2 only)
[25] Delayed Fire and Burglary: Functions as a Fire and Burglary output but does not activate until the TX Delay time expires
[26] Battery Test Output: Output activates for 10 seconds at midnight each day.
[28] Holdup Output: Activates when a Holdup Alarm occurs on any assigned partition. Remains active until all assigned partitions have been
armed or disarmed. Will not activate if a Holdup Zone is goes into a fault or tamper condition.
[29] Zone Follower (Zones 1-8): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[30] Partition Status Alarm Memory: Activates if the selected partition is armed.
Output will pulse “one second ON / one second OFF if an alarm occurs
[31] Alternate Communicator: Activates when selected system event occurs. If active in the armed state, it remains active until the system is
disarmed. If activated in the disarmed state, it remains active until a valid access code is entered within bell cut-off time, or when the system
is armed after bell cut-off time has expired.
[32] Open After Alarm: Actives for 5 seconds when system has been disarmed after an alarm.
[33] Bell Status and Programming Access Output: Activates when Bell, Installer programming mode or DLS is active. Remains active until
Bell is no longer active, Installer programming mode is exited and DLS programming is disconnected.
[34] Away Armed with no Zone Bypassed Status: Activates when armed with stay/away zones active and no zones bypassed.
[35] Zone Follower (Zones 9-16):
Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[36] Zone Follower (Zones 17-24): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[37] Zone Follower (Zones 25-32): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[38] Zone Follower (Zones 33-40): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[39] Zone Follower (Zones 41-48): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[40] Zone Follower (Zones 49-56): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
[41] Zone Follower (Zones 57-64): Active when any of the selected zones are active and deactivates when all of the selected zones are restored.
* See Section [501]-[514] Programmable Output Attributes, PGM Output Option [29] and [35]-[41] option 8 on page 23
Option Description
[1] ON: zones require normally-closed loops. OFF: zones require 5.6K End-Of-Line resistors.
[2] ON: zones require double End-Of-Line resistors. OFF: zones require single End-Of-Line resistors.
[3] ON: keypads will display all trouble conditions while armed. OFF: keypads will only display fire trouble when armed.
This option must be OFF if LCD5500 v2.x (or older) keypads are used on the system.
[4] ON: only a trouble will be displayed. OFF: keypads will display a trouble and a zone violation if a tamper or fault is detected.
