PowerSeries - PC1616/PC1832/PC1864
28
5.2 Programming Worksheets
Shaded programming sections indicate minimum programming requirements
SIA FAR CP-01 defaults are indicated in gray text.
Keypad Partition /Slot and Function Key Programming
[000] Keypad Enrollment
This must be done at each keypad requiring programming.
[0] Slot address [Valid entries are 0-8 for the partition, 1-8 for the slot. (e.g., to enroll a keypad in partition 3 and slot 1, enter (31)]
[1] Function Key 1 Assignment (Valid entries are 00-33)
[2] Function Key 2 Assignment (Valid entries are 00-33)
[3] Function Key 3 Assignment (Valid entries are 00-33)
[4] Function Key 4 Assignment (Valid entries are 00-33)
[5] Function Key 5 Assignment (Valid entries are 00-33)
Function Key Options:
[001]-[004] Zone Definitions
00 Not used 11 [*][5] Access Code Programming 22 Global Disarming
01 Select Partition 1 12 [*][6] User Functions 23 Bypass Recall
02 Select Partition 2 13 Command Output #1 [*][7][1] 24 Recall Bypass Group
03 Stay Arm 14 Command Output #2 [*][7][2]/Sensor Reset 25 For Future Use
04 Away Arm 15 Global Stay Arming 26 Time and Date
05 [*][9] No-Entry Arm 16 [*][0] Quick Exit 27 Select Partition 3
06 [*][4] Chime On / Off 17 [*][1] Reactivate Stay/Away Zones 28 Select Partition 4
07 [*][6][——][4] System Test 18 Global Away Arming 29 Select Partition 5
08 [*][1] Bypass Mode 19 Command Output 3 [*][7][3] 30 Select Partition 6
09 [*][2] Trouble Display 20 For Future Use 31 Select Partition 7
10 [*][3] Alarm Memory 21 Command Output 4 [*][7][4] 32 Select Partition 8
33 Activate Local PGM
Partition/
Slot
[20] Zone
Assigned
Key 1 Key 2 Key 3 Key 4 Key 5
ICON / LED Defaults
11 00 03 04 06 14 16
Full Message Defaults
18 00 03 04 06 14 16
KEYPAD 1
00
KEYPAD 2
00
KEYPAD 3
00
KEYPAD 4
00
KEYPAD 5
00
KEYPAD 6
00
KEYPAD 7
00
KEYPAD 8
00
00 Null Zone (Not Used) 12 24 Hour Holdup* 25 Interior Delay*
01 Delay 1* 13 24 Hour Gas* 26 24 Hour Non-alarm*
02 Delay 2* 14 24 Hour Heating* 29 Auto Verified Fire
03 Instant* 15 24 Hour Auxiliary* 30 Fire Supervisory
04 Interior* 16 24 Hour Panic* 31 Day Zone*
05 Interior, Stay/Away* 17 24 Hour Emergency* 32 Instant Stay/Away*
06 Delay, Stay/Away* 18 24 Hour Sprinkler* 35 24-hour Bell/Buzzer
07 Delayed 24 Hour Fire (Hardwired)** 19 24 Hour Water* 36 24 Hour Non-Latching Tamper Zone
08 Standard 24 Hour Fire (Hardwired) 20 24 Hour Freeze* 37 Night Zone
09 24 Hour Supervisory 21 24 Hour Latching Tamper* 87
Delay 24 Hour Fire (Wireless/Addressable)**
10 24 Hour Supervisory Buzzer* 22 Momentary Keyswitch Arm* 88 Standard 24 Hour Fire (Wireless/Addressable)**
11 24 Hour Burglary* 23 Maintained Keyswitch Arm*
*For burglary applications only ** For residential fire applications only
