15.1 Calibration mode
GOBO WHEEL INDEX GOBO FIXED WHEEL IRIS ZERO
ALIGNMENT ALIGNMENT ALIGNMENT
To aligh Gobo wheel index To align Gobo fixed wheel Iris zero position setting
IRIS PATH PRISM ZERO PRISM PATH
ALIGNMENT ALIGNMENT ALIGNMENT
Iris excursion setting Prism zero position setting Prism excursion setting
FOCUS ALIGNMENT ZOOM ALIGNMENT
To align FOCUS To align ZOOM
16- PAN SPEED & TILT SPEED
You can set the PAN and TILT motors at high speed on your JACK.
Press menu until you see PAN SPEED/TILT SPEED.
Press ENTER and select a speed with UP-DOWN (there are 8 speeds).
Confirm by pressing ENTER.
17- BASE FANS SPEED AND LAMP FANS SPEED
Base Fans speed and Lamp Fans speed regulation makes it possible to reduce fan
noise.
However, the ambient temperature must be less than 35° C.
