4- TECHNICAL FEATURES
The JACK is a high-power, compact, lightweight moving head.
JACK features a wide excursion motorized zoom allowing any application from
long-throw projections to large wall washing.
Beam opening is:
1° - 2,5° 'Beam' projection;
2,5° - 37° 'Spot' projection;
38° - 46° 'Wash' projection.
JACK generates a huge luminosity and extremely uniform projection using only a
189 W lamp; power consumption is just 230W.
Also, JACK comes equipped with the 'FPR' ( 'Free Pan Rotation' - patent pending )
system, which allows limitless pan rotation, in either direction, never having to reverse
motion (Cod. 03.MS012.EBLFP).
JACK is the perfect moving head for rental companies – who want a quick and easy to
install unit – thanks to its compactness and light weight (only 11,9 Kg).
JACK is suitable for any professional applications.
JACK
(Cod. 03.MS012.EB.L)
• Electronic ballast 90-260V 50/60 Hz • Black finish
Also available with white finish (RAL 9003) on demand (03.MS012.EB.03.L)
(Cod. 03.MS012.EBLFP)
• Electronic ballast 90-260V 50/60 Hz • FPR (Free Pan Rotation) Black finish
Also available with white finish (RAL 9003) on demand (03.MS012.EB03LFP)
Lamp
MSD Platinum 5R (7.950 Lumens)
Colour temperature: 8.000°K
Type of connection: PINS 2,8x 0,8mm
Optical group
* 50,000 Lux at 5 m (2,5°)
* Improved optical group made with 11 coated lenses
combined with a dichroic glass reflector
* 16-bit motorized linear zoom (2,5°- 46°)
* Beam opening: 1°- 46°
* 16-bit motorized focus
* Motorized iris
* Linear dimmer / shutter / strobe (0,85 flash/sec to 10 flash/sec)
Colour generation
* 18-colour wheel with linear selection for perfect 2-colour beams
Dynamic effects
Overlapping wheels for multiple effects:
* Customizable rotating gobo wheel (9 gobos)
* Customizable fixed gobo wheel (10 gobos)
* 4-facet rotating prism
