DTS JACK User Manual

26
22- DMX PROTOCOL
25 CHANNELS MODE (DEFAULT)
1 PAN msb
2 PAN lsb
3 TILT msb
4 TILT lsb
5 SPEED MOVEMENT
6 PAN FAR (Active only on Jack FPR Cod. 03.MS012.EBLFP)
7 DIMMER
8 SHUTTER
9 COLOUR
10 COLOUR MODE
11 GOBO
12 GOBO MODE
13 GOBO ROTATION / INDEX – PRISM ROTATION
14 GOBO INDEX FINE
15 GOBO SHAKE
16 FIXED GOBO
17 FIXED GOBO SHAKE
18 IRIS
19 MACROS
20 MACROS MODE
21 PRISM
22 FOCUS
23 FOCUS FINE
24 ZOOM
25 RESET + LAMP
DMX CHANNEL
1
Parameter: PAN msb
DMX CHANNEL
2
Parameter: PAN lsb
DMX CHANNEL
3
Parameter: TILT msb
DMX CHANNEL
4
Parameter: TILT lsb
DMX CHANNEL
5
Parameter: SPEED MOVEMENT
DMX value
Function
000-010
Standard
011-025
Fast movement
026-127
Vector mode from fast to slow
128-247
Variable time reaction to DMX signal (fast to slow)
248-255
Silent movement
