DTS JACK User Manual

27
DMX CHANNEL
6
Parameter: PAN FAR (Active only on Jack FPR Cod. 03.MS012.EBLFP)
DMX value
Function
000-010
Position mode 540° (standard path)
011-020
Position mode 360° (1 turn)
021-030
Position mode 720° (2 turns)
031-040
Position mode 1080° (3 turns)
041-050
Position mode 1440° (4 turns)
051-060
Position mode 1800° (5 turns)
061-070
Position mode 2160° (6 turns)
071-080
Position mode 2520° (7 turns)
081-090
Position mode 2880° (8 turns)
091-100
Position mode 3240° (9 turns)
101-110
Position mode 3600° (10 turns)
111-120
Position mode 360° smart path
121-182
Forward spin rotation speed from max to min
183-193
Stop
194-255
Reverse spin rotation speed from min to max
DMX CHANNEL
7
Parameter: DIMMER
DMX value
Function
000-007
Black-out
008-255
Proportional dimmer
DMX CHANNEL
8
Parameter: SHUTTER
DMX value
Function
000-019
Black-out
020-039
Open
040-059
Black-out
060-079
Strobe random speed
080-089
Strobe speed 1
090-099
Strobe speed 2
100-109
Strobe speed 3
110-119
Strobe speed 4
120-129
Strobe speed 5
130-139
Strobe speed 6
140-149
Flash open speed 1
150-159
Flash open speed 2
160-169
Flash open speed 3
170-179
Flash open speed 4
180-189
Flash closed speed 1
190-199
Flash closed speed 2
200-209
Flash closed speed 3
210-219
Flash closed speed 4
220-227
Colours / Gobo in black-out
228-233
Pan / Tilt in black-out
234-255
Open
