DTS JACK User Manual

28
DMX CHANNEL
9
Parameter: COLOUR
IF CHANNEL 10 = FULL COLOUR (DMX range value 0-63)
DMX value
Function
000-013
Colour 1
014-027
Colour 2
028-041
Colour 3
042-055
Colour 4
056-069
Colour 5
070-083
Colour 6
084-097
Colour 7
098-111
Colour 8
112-125
Colour 9
126-139
Colour 10
140-153
Colour 11
154-167
Colour 12
168-181
Colour 13
182-195
Colour 14
196-209
Colour 15
210-223
Colour 16
224-237
Colour 17
238-255
Colour 18
IF CHANNEL 10 = HALF COLOUR (DMX range value 64-127)
DMX value
Function
000-012
Colour 1
013-025
Colour 1-2
026-038
Colour 2-3
039-051
Colour 3-4
052-064
Colour 4-5
065-077
Colour 5-6
078-090
Colour 6-7
091-103
Colour 7-8
104-116
Colour 8-9
117-129
Colour 9-10
130-142
Colour 10-11
143-155
Colour 11-12
156-168
Colour 12-13
169-181
Colour 13-14
182-194
Colour 14-15
195-207
Colour 15-16
208-220
Colour 16-17
221-233
Colour 17-18
234-255
Colour 18-1
IF CHANNEL 10 = PROPORTIONAL COLOUR (DMX range value 128-191)
DMX value
Function
000-010
No Colour
011-255
Proportional Colour
IF CHANNEL 10 = RAINBOW (DMX range value 192-255)
DMX value
Function
000-009
No Colour
010-127
Right rotation speed from max to min
128-137
Stop
138-255
Left rotation speed from min to max
DMX CHANNEL
10
Parameter: COLOUR MODE
DMX value
Function
000-063
Full Colour
064-127
Half Colour
128-191
Proportional Colour
192-255
Rainbow
