13- DISPLAY FUNCTIONS
Base Fans Base Fans speed control
1-12 (Default = 4)
BASE FANS
Base Fans speed control
Lamp Fans Lamp Fans speed control
1-12 (Default = 5)
LAMP FANS
Lamp Fans speed control
Gobo Rotation ON
OFF = (Default)
GOBO ROTATION
Gobo rotation during gobo scrolling
for rotating gobo wheel
Auto Focus ON
OFF = (Default)
AUTO FOCUS (Auto focus function not yet
Automatic focusing implemented)
System info SYSTEM INFO
SYSTEM INFO Lamp life time, lamp strikes,
Lamp life time, lamp strikes, unit life time, 8 motors card
unit life time, 8 motors card software version, Pan&Tilt
software version, Pan&Tilt card card software version and
software version and unit model unit model
Reserved
RESERVED Pan Lock = Lock the Pan
Pan lock-Tilt lock to the desired value
Pan free-Tilt free Tilt Lock = Lock the Tilt to
System Reboot the desired value
(Code = 100) Pan Free = Remove power
to Pan motor
Tilt Free = Remove power
to Tilt motor
System Reboot = Unit
Reboot without needing
of turning OFF the unit
Up-Down
Menu
ENTER
ENTER
Up-DownENTER
Up-DownENTER
Up-Down
Menu
GOBO ROTATION
OFF
MENU ENTER DOWN UP
During gobo scrolling
RESERVED
000
MENU ENTER DOWN UP
ENTER CODE
PAN LOCK
NO
MENU ENTER DOWN UP
Up-Down
Menu
Up-Down
Menu
Up-Down
Menu
Up-Down
Menu
Up-DownENTER
Up-DownENTER
Up-DownENTER
Up-DownENTER
ENTER
ENTER
ENTER
ENTER
SYSTEM INFO
LAMP LIFE:0024H STRIKE:048
UNIT LIFE: 0024H
9M R.34
PT R.23
MODEL: JACK
MENU ENTER DOWN UP
AUTO FOCUS
OFF
MENU ENTER DOWN UP
BASE FANS
4
MENU ENTER DOWN UP
1=13V 12=24V
LAMP FANS
5
MENU ENTER DOWN UP
1=13V 12=24V
