DTS JACK - DMX Protocol - 25 Channels Mode; DMX Channel 11: GOBO; DMX Channel 12: GOBO MODE; DMX Channel 13: GOBO ROTATION; INDEX - PRISM ROTATION

29
DMX CHANNEL
11
Parameter: GOBO
DMX value
Function
000-020
Open
021-041
Gobo 1
042-062
Gobo 2
063-083
Gobo 3
084-104
Gobo 4
105-125
Gobo 5
126-146
Gobo 6
147-167
Gobo 7
168-188
Gobo 8
189-207
Gobo 9
208-213
Speed rotation 1 min
214-219
Speed rotation 2
220-225
Speed rotation 3
226-231
Speed rotation 4
232-237
Speed rotation 5
238-243
Speed rotation 6
244-249
Speed rotation 7
250-255
Speed rotation 8 max
DMX CHANNEL
12
Parameter: GOBO MODE
DMX value
Function
000-127
Gobo Rotation Mode
128-255
Gobo Index Mode
DMX CHANNEL
13
Parameter: GOBO ROTATION / INDEX – PRISM ROTATION
GOBO MODE ROTATION
DMX value
Function
000-009
Stop
010-127
Left rotation (max to min)
128-137
Stop
138-255
Right rotation (min to max)
GOBO MODE INDEX
DMX value
Function
000-255
Gobo Index Coarse
DMX CHANNEL
14
Parameter: GOBO INDEX FINE
DMX value
Function
000-255
Gobo Index Fine
