DTS XR7 WASH User Manual

1- TECHNICAL FEATURES
- New motorized moving head
- ABS cover
- 200mm fresnel lens
- MSR575/2 lamp
- Control: max 16 channels DMX
- Fast, silent and precise movement
- Position controlled pan (540°) and tilt (320°) by encoder
- Motorized zoom (16°-28°)
- Colour mixing by CMY
- Colour wheel with 6 dichroic high chromatic yield filters +2 filters for
temperature colour conversion 3200°K and 5600°K + Rainbow effect
- Effects wheel with modulation of beam shape 0 180° and Frost effect.
- Mechanical dimmer
- Strobe effect
- Display for settings and addresses
- Possibility of regulating internal fans and motors to adjust to the
temperature in which the unit is functioning
- Possibility to function autonomously
- Weight: 26Kg
1
660
450
360

DTS XR7 WASH Specifications

General

Brand	DTS
Model	XR7 WASH
Category	Flood Light
Language	English
