Dual ALB12 - Connections and Controls

5
LineIn(Left)
LineIn(Right)
CrossoverFrequency
InputLevelControl
PhaseControl
1 6
2 7
3 8
4 9
Power Indicator
GroundConnection
RemoteConnection
PowerConnection
Fuse(15A)
Connections and Controls
