Preparation
MOUNTING SLEEVE
REMOVAL KEYS
TYPICAL MOUNTING METHOD
MR100 INSTALLATION
Please read entire manual before installation.
Before You Start
•Disconnectnegativebatteryterminal.Consultaqualifiedtechnicianforinstructions.
•Avoidinstallingtheunitwhereitwouldbesubjecttohightemperaturesorwhereit
wouldbesubjecttodust,dirtorexcessivevibration.
Getting Started
•Insertthesuppliedkeysintotheslotsasshown,andslidetheunitoutofthemounting
sleeve.
•Installmountingsleeveintoopening,bendingtabstosecure.
•Connectwiringharnessandantenna.Consultaqualifiedtechnicianifyouareunsure.
•Testforcorrectoperationandslideintothemountingsleevetosecure.
•Snaptrimringintoplace.
Mountingsleeveopeningdimensions
7-11/64"x2-3/32"(182mmx53mm)
