Dual XIA2340 - Specifications (XIA2340)

10
XIA SERIES OPERATION
Specifications
CEA-2006 Power Standard Specifications
(reference: 14.4VDC, 20Hz~20kHz)
Power Output: 70 Watts RMS x 2 channels at 4 ohms and <
1% THD+N
Signal to noise ratio: 70dBA (reference: 1 watt into 4 ohms)
Additional power output:
90 Watts RMS x 2 channels at 2 ohms and <
1% THD+N
200 Watts RMS x 1 channel at 4 ohms (bridged) and <
1% THD+N
Dynamic power: 340 Watts at 4 ohms
Frequency response: 20Hz~20kHz (-3dB)
Maximum input signal: 6V
Minimum input signal: 200mV
Speaker output impedance: 2~8 ohms (stereo), 4~8 ohms (bridged)
illuminite output voltage: 12VDC
illuminite output current: 2 amp
Low level input range: 200mV~6V (10k ohms)
High level input range: 2V~10V (100 ohms)
Bass boost: 0~12dB @ 45Hz
Crossover range: 40~400Hz
Crossover slope: 12dB/octave
Power supply: 11-16 VDC, negative ground
Fuses: 30 amp, 2 amp ATO
Amplifier dimensions: 12.6" x 2.56" x 11.14" (WxHxD)
(320 x 65 x 283 mm)
Typical installation dimensions: 15" x 3.5" x 11.14" (WxHxD)
(381 x 89 x 283 mm)
XIA2340
