Duali DQ-MINI - 1 Introduction; 2 Specification

DQ-MINI User Manual, Version: 1.00
www.duali.com 5
01. Introduction
DQ-MINI is a wiegand access control reader based on 13.56 Mhz contactless card
communication technology with stylish and rugged design. And it also can read QR code and
1D/2D barcode. The ideal combination of NFC & QR reader could upgrade your application into
another level. The reader is designed for wall mounting type of Access / Time attendance &
parking management systems, and etc.
02. Specification
Communication Interface
Wiegand - 32 / 34 /56/ 58/ 64/ 66 bit
RS-232 – 115200bps
RS-485 – 115200bps
Operating Frequency
13.56MHz
Credential Type
Contactless
> ISO 14443 TYPE A and B
> Mifare™
> FeliCa®
> ISO 15693
> ISO 18092 (NFC)
[Option]
Contact (SAM)
> ISO7816 Class A (5V)
2 SAM Card Slot
1D/2D QR
Recognizable spec
UPC/EAN, UPC/EAn with Supplementals, Bookland
EAN, ISSN, UCC Coupon Extended Code, Code128,
GS1-128, ISBT 128, Code 39, PDF417,
MicroPDF417, Composite Codes, Data Matrix,
Maxicode, Qr Code, micro QR, Aztec
Indicator
LED (RED /BLUE)
Magnetic Buzzer
Power Supply
12VDC (9- 12 VDC also available)
Linear supply recommended, 150 mA @ 12 VDC
Operating Condition
> -4º to 158ºF (-20º to 70ºC guaranteed)
> 5% to 90% relative humidity
Storage Condition
> -4º to 158ºF (-20º to 80ºC) >
> 5% to 90% relative humidity
Housing Material
PC (polycarbonate)
Dimensions
99.3(mm) x 91.9(mm) x 88.4(mm)
Weight
169.6g
Cable length
1000(mm)
Certifications
FCC Certification (US), CE(EU), IP65 compliant
