Ducati 999R User Manual

E
57
Checking and topping up the coolant level (fig. 53)
Check the coolant level in the expansion reservoir, on the
RH side of the motorcycle. The coolant level must be
between the marks (1) and (2). The longest mark (2)
indicates MAX level, whereas the shortest mark (1)
indicates MIN level.
Top up if the level is below the MINIMUM level.
Note
For a good view of the coolant level, look at the tank
from the left side of the motorcycle. Look down between
front wheel and right fairing.
2
1
fig. 53

Ducati 999R Specifications

General

Transmission	6-speed
Frame	Tubular steel trellis
Bore x Stroke	104 x 58.8 mm
Power	140 hp (104 kW) @ 9750 rpm
Torque	108 Nm @ 8, 000 rpm
Rear Suspension	Öhlins fully adjustable monoshock
Front Brakes	Dual 320mm discs, 4-piston calipers
Rear Brakes	240 mm disc, 2-piston caliper
Fuel Capacity	15.5 liters
Fuel Injection	Electronic fuel injection
Front Suspension	Öhlins 43 mm fully adjustable upside-down fork
