Instrument panel diagnostics
Important
The instrument runs the system diagnostics correctly
60 seconds after the last Key-Off.
This function allows you to display and identify malfunctions
of the motorcycle and, where possible, replace components
identified as faulty.
To view this function, access the “Error“ page of the menu.
This menu is only active when at least one error is present,
otherwise the page will NOT appear.
If there are several errors, they are displayed in rolling mode
every 3 seconds.
In any case, a more detailed diagnosis can be obtained using
the Ducati Diagnostic System.
Warning
When an error is displayed, always contact a Ducati
Dealer or authorised Service Center.
WARNING LIGHT ERROR MESSAGE ERROR
TPS 01 Throttle position sensor short circuit Volt DC or AC
TPS 01 Throttle position sensor short circuit GND
PRESS 02 Throttle position sensor short circuit Volt DC
PRESS 02 Throttle position sensor short circuit GND or AC
OIL 03 Oil NTC sensor short circuit Volt DC or AC
OIL 03 Oil NTC sensor short circuit GND
T AIR 04 Air temperature sensor short circuit GND or AC
