Ducati MONSTER 2012 - Rear Brake Pedal; Gear Change Pedal

57
E
Rear brake pedal (fig. 42)
Push down on the pedal (1) with your foot to operate the rear
brake.
The system is controlled hydraulically.
Gear change pedal (fig. 43)
The gearchange pedal has a central position N, with
automatic return, and two directions of movement:
down = press down the pedal to engage the 1
st
gear and to
shift down. At this point the N warning light on the
instrument panel will go out;
upwards= lift the pedal to engage 2
nd
gear and then 3
rd
, 4
th
,
5
th
and 6
th
gears.
Each time you move the pedal you engage the next gear up,
one gear at a time.
1
fig. 42
1
2
3
4
5
6
N
fig. 43
