Ducati Monster 600 - Legend of the Wiring Diagram of Electric and Ignition Systems

109
LEGEND OF THE WIRING DIAGRAM
OF ELECTRIC AND IGNITION SYSTEMS
(see page 245)
1) Headliamp
2) Front right-turn indicator
3) Front left-turn indicator
4) Horn
5) Number plate light
6) Odometer
7) Instrument panel warning lights
8) Regulator
9) Key-operated switch
10) R.H. twistgrip switch
11) L.H. twistgrip switch
12) Front stop light switch
13) Rear stop light switch
14) Neutral light switch
15) Oil pressure sensor
16) Side stand switch
17) Fuel level indicator
18) Rear, left-turn indicator
19) Main relay
20) Flasher
21) Generator
22) Ignition pick-up
23) Ignition module
24) Tail light
25) Fuse holder 40A
26) Horizontal cylinder coil
27) Vertical cylinder coil
28) Horizontal cylinder spark plug
29) Vertical cylinder spark plug
30) Fuse box
31) Starter motor
32) Starter solenoid
33) Battery
34) Rear right-turn indicator
Wire color coding
R Red
G Green
Y Yellow
O Orange
GR Grey
BN Brown
BK Black
P Pink
W White
W-R White-Red
W-G White-Green
GR-R Grey-Red
R-BK Red-Black
O-B Orange-Blue
Y-G Yellow-Green
Y-BK Yellow-Black
W-BK White-Black
W-G White-Green
R-B Red-Blue
B-BK Blue-Black
W-Bn White-Brown
R-Y Red-Yellow
W-Y White-Yellow
Bn-Bk Brown-Black
Legend of fuse box (30)
Pos. Description Rat.
A-1 Main switch 30 A
B-2 Ignition, regulator 7.5 A
C-3 High and low beams 15 A
D-4 Trun indicators, warning lights, 7.5 A
tail lights and instrument panel
lights
E-5 Stop, warning horn 7.5 A
F-6 Spare fuse 30 A
G-7 Spare fuse 15 A
H-8 Spare fuse 7.5 A
