117
TORQUE FIGURES Thread Nm Ft.lbs
± 5% tolerance ± 5% tolerance
Spark plugs M12x1.25 20 14.75
Front wheel spindle (molybdenum disulphide grease) M18x1.5 72 53.10
Front wheel spindle set screws (molybdenum disulphide grease) M8x1.25 22 16.23
Rear sprocket flange check nut (LOCTITE 242 with reaction) M10x1.25 46 33.93
Rear wheel nut (molybdenum disulphide grease) M16x1.5 72 53.10
Chain tensioner adjusting screw (medium-fiber lithium-based grease of the multi-purpose type) M8x1.25 8 2.11
