1.3 Technical Specification
Number of stitches: 1.650 Stitches/min
Type of stitch: Double chain stitch
Sewing length: max. 50 mm
Cutting length: max. 50 mm
Needle system: 558
Needle thickness: Nm 90...110
Depending on the type of sewing thread and the material.
Looping stroke: 2.7...3.2 mm
Depending on the sewing device (E no.).
Material thicknesses: max. 10 mm with sub-class -221301
max. 12 mm with all othersub-classes
Sewing thread thickness: Upper thread max. Nm 50
Underthread max. Nm 30
Nominal voltage: - 2410591 3 ~ 400 V + N, 50/60 Hz
- 2410575 3 ~ 230 V, 50/60 Hz
- 2410540 1 ~ 230 V, 50 Hz
- 2410478 1 ~ 230 V, 60 Hz
The machine is delivered with one of the listed drive
packages appropriate to the nominal voltage.
Noise: Lc = 80 dB (A)
by sewing cycle 5.0 s on and 1.4 s off
to DIN 45635-48-B-1
Dimensions: (H x W x D) 1570 x 630 x 520 mm (Standard)
1570 x 1060 x 520 mm (Wide model)
Weight: 128 kg (complete with machine head,
frame and motor)
55 kg (only frame and motor)
Work height: 760...1060 mm (Top edge of table)
7
