Dufour 41 - Deck Fittings Plan

ENGLISH 11-07-2023 37/95 DUFOUR 41
3. Deck fittings plan
REF.
DESCRIPTION
COMMENTS
A
GRAB-LINE ANCHOR POINTS
Port and Starboard cleats
B
TOWING POINTS
Port and Starboard
C
HATCHES THAT MUST BE KEPT CLOSED WHEN SAILING
D
“MAN OVERBOARD” BOARDING LADDER
E
LOCATION OF THE LIFE RAFT
F
SAFETY HARNESS ATTACHMENT POINT
G
LOCKER - MUST BE KEPT CLOSED WHEN SAILING
1
ANCHOR ROLLER
2
WATERTIGHT CHAIN PLATE D10
3
WATERTIGHT CHAIN PLATE D10
OCEAN PACK (SPI)
4
HINGED CHAIN PLATE D6
5
HINGED CHAIN PLATE D8
6
SINGLE JAM-CLEAT
FURLING LINE
7
SINGLE JAM-CLEAT
OCEAN PACK
8
SINGLE JAM-CLEAT
OPT RELEASABLE STAY
9
DOUBLE JAM-CLEAT
10
DOUBLE JAM-CLEAT
OCEAN PACK
11
ORGANISER 3
OCEAN PACK
12
BOX SHEAVE WITH 5 SHEAVES
13
SINGLE BOW RAIL
14
PORT STERN RAIL
15
STARBOARD STERN RAIL
16
CENTRAL RAIL
17
SWIM LADDER
18
COACHROOF HANDRAIL
19
SELF-TACKING JIB TRACK
20
GENOA TRACK
OCEAN PACK
21
ALUMINIUM MOORING CLEAT
22
WINCH ROOF
23
COAMING WINCH
OCEAN PACK
24
STAND-UP PULLEY
25
CRANK CASE
26
CRANK CASE
OCEAN PACK
