Dufour 41 - 220 V Electrical Panel Diagram

ENGLISH 11-07-2023 50/95 DUFOUR 41
6. 220 V Electrical panel diagram
Ref.
Description
A
SHORE POWER PROTECTION BOX
B
DISTRIBUTION UNIT
1
DIFFERENTIAL CIRCUIT-BREAKER
32A
2
CHARGER CIRCUIT-BREAKER
16A
3
WATER HEATER CIRCUIT-BREAKER
16A
4
CIRCUIT-BREAKER, SOCKETS -1
16A
5
CIRCUIT-BREAKER, SOCKETS -2
16A
6
“MAINS PRESENT” LED
7
“REVERSED POLARITY” LED
