Dufour 41 - Location of Thru-Hull Fittings

ENGLISH 11-07-2023 81/95 DUFOUR 41
21. Location of thru-hull fittings
Ref.
Function
Ø
A
TOILET DISCHARGE
2’’
B
DISCHARGE FOR WASHBASIN / SHOWER HEAD
COMPARTMENT (2 CABINS)
1’’
C
GALLEY SEAWATER PUMP INLET
1/2’’
D
GALLEY DISCHARGE
1’’ 1/4
E
GENERATOR WATER INLET*
3/4'’
F
TOILET WATER INLET
3/4'’
G
GENSET DISCHARGE*
1’’ 1/4
H
EXTERIOR SINK WATER DISCHARGE*
1’’
I
MANUAL BILGE PUMP DISCHARGE
1’’
J
ELECTRIC BILGE PUMP DISCHARGE
1’’
K
WATERMAKER DISCHARGE*
1/2’’
L
WATERMAKER INLET*
3/4'’
M
AIR CONDITIONING WATER DISCHARGE*
1/2’’
N
AIR CONDITIONING WATER INLET*
3/4'’
O
AIR CONDITIONING CONDENSATES DISCHARGE*
1/2’’
*
Option
