Dufour 41 - Diagram Showing Fuse Locations

ENGLISH 11-07-2023 58/95 DUFOUR 41
10. Diagram showing fuse locations
ZONE
PROTECTION
FUNCTION
A 12V
Blade fuse 400A
TUNNEL THRUSTER*
A 12V
Circuit-breaker 110A
WINDLASS*
A 12V
Fuse 160A
WINDLASS IF NO THRUSTER
B 12V
Fuses
(see TABLE 12V)
B 12V
Fuse 10A
SEAWATER PUMP
B 12V
Fuse 25A
ELECTRIC WC*
B 12V
Fuse 10A
TUNNEL THRUSTER*
B 12V
Fuse 10A
GAS SOLENOID*
C 12V
Fuse 10A
BILGE FAN
C 12V
Fuse 30A
AUTOPILOT
C 12V
Fuse 5A
WINDLASS CONTROL
C 12V
Blade Fuse 200A
HOUSE BATTERIES PROTECTION
C 12V
Blade Fuse 325A
INVERTER PROTECTION
C 12V
Fuse 5A
ENGINE BATTERY INFO
C 12V
Fuse 5A
HOUSE BATTERY INFO
D 12V
Circuit-breaker 110A
ELECTRIC WINCH*
E 230V
Circuit-breaker 16A
AIR CONDITIONING - FORWARD CABIN*
E 230V
Circuit-breaker 20A
AIR CONDITIONING - SALOON*
E 230V
Circuit-breaker 16A
AIR CONDITIONING - AFT CABIN*
E 230V
Diff Circuit-breaker 32A/30 mA
AIR CONDITIONING*
E 230V
Diff Circuit-breaker 32A/30 mA
230V PANEL
E 230V
Diff Circuit-breaker 32A/30 mA
INVERTER
E 230V
Circuit-breaker 10A
CHARGER
E 230V
Circuit-breaker 10A
WATER HEATER
E 230V
Circuit-breaker 10A
230V SOCKETS
E 230V
Circuit-breaker 25A
GENSET*
E 230V
Circuit-breaker 32A
AIR CONDITIONING SHORE POWER SOCKET*
E 230V
Circuit-breaker 32A
SHORE POWER SOCKET
*
OPTION
