22. Engine layout diagram
Ref.
Description
1
Engine control unit
2
Engine control panel
3
Rev counter
4-5
Seawater cooling pipes ϕ25
6-7
Cooling pipe ϕ32
8
Anti-siphon swan neck - V type
9
Exhaust pipe ϕ60
10
Seawater pre-filter
11
Exhaust outlet ϕ60
12
Exhaust pipe (ϕ as per the engine)
13
Waterlock
14
Engine insulating foam
15
Engine circuit breaker
16
Starter battery 75 Ah
17
Charge divider
18
Diesel filler deck plate
19
Propeller (as per the motorisation or option)
20
Polyester engine mount
21
Sail-Drive
22
Propulsion engine (as per option)
