Dufour 41 - Electrical Layout Diagram

ENGLISH 11-07-2023 66/95 DUFOUR 41
14. 12 V Electrical layout diagram
Ref.
Description
1
Charge divider
2
Shunt
3
Induction charger
4
House batteries
5
12 V Terminal strip
6
Electric winch motor
7
Electric winch relay box
8
Windlass control
9
Windlass relay
10
Windlass
11
Port – starboard navigation lights LED
12
Stern light LED
13
Bilge pump buzzer
14
Compass
15
USB socket
16
Tunnel thruster*
17
Submerged bilge pump
18
Pressurised water unit
19
VHF *
20
Autopilot*
21
Engine battery
22
12V PANEL
23
Refrigeration unit
*
Option
