Dufour CATAMARAN 48 - Steering System; Manouver Bar; Emergency Tiller

35
DY CAT 48
X. STEERING SYSTEM
The steering system is an essential element for the safety and comfort of your ship.
Manouver Bar
The DY CAT 48 is equipped with a wheel with wires system and chains as well as a spare bar. The
main component of the systems is located in the starboard engine room.
Periodic checks to be carried out:
Check the set of the various elements (rudder wick/bearings, tension and wear of the mechanical
parts) and lubricate if necessary sprocket and chain.
In case of doubt or problem, consult your dealer.
Emergency Tiller
ATTENTION !
• The DY CAT 48 is equipped with a free emergency bar which must be easily accessible,
we recommend storing it in a cockpit safe.
• It is designed only for low speed navigation in case of damage to the bar.
To use it:
- Unscrew the cap using the handle
- Place the bar on the rudder's wick head
