Dufour CATAMARAN 48 - Deck Plan

47
DY CAT 48
2. Deck Plan
Ref.
Description
A
Fuel Cap DN 50
B
Fresh Water Cap DN 38
C
Black Water Dock DN 50 (1 each Black Water Tank)
D
Anchor **
E
Bollard
F
Life Raft **
G
Fuel Manual Stop Handle
H
Fire Manual Handle for activating fire-estinguisher
I
Manual Pump
L
Windows imperatively Closed in NAVIGATION
M
Emergency ladder **
N
Harness Attachment Point for Lifeline (Bollard)
O
Hatches imperatively Closed in NAVIGATION
P
Air Inlet Grill 125 mm x 125 mm
Q
Air Outlet Grill 85 mm x 85 mm
**
Not supply with the boat
